IncOder™ CORE Inductive Angle Encoder

Novanta’s inductive encoders are capable of operating under the harshest conditions without compromising any accuracy.

Robust Angular Position Measurement in a Lightweight Unpackaged Design

IncOders are non-contact devices for precision angle measurement. IncOder CORE does away with the machined aluminium IncOder housing, enabling an ultra lightweight design, reducing system weight and maximizing sensor integration within the end application.

Utilizing the same robust patented sensor technology as IncOder – IncOder CORE are ideally suited to harsh environments, delivering a precise measurement with up to 20 bits resolution.

To IncOder Features

Compact Bearingless Form Factor

IncOder CORE contains 2 main parts – a Stator and a Rotor – each shaped like a flat ring. The large bore makes it easy to accommodate through-shafts, optical-fibres, or cables.

IncOder CORE is available in compact sizes – 44mm and 70mm Outer Diameter – both featuring a large thru-bore and stacked stator design. Each sensor features mechanical mounting features within the PCB simplifying installation and integration.

To Safety Specifications

Economically Priced for Large Volume Production

Novanta recognizes the need for customers to meet component cost targets, particularly when applications are scaling to significant production volumes. IncOder CORE provides an avenue for selecting an extremely robust absolute inductive angle sensor in an economically priced package.

To IncOder Features

Overview & Features

Specifications

Documents & Downloads

Accessories

CAD Downloads

Overview

No calibration or precision installation tolerances. Guaranteed accuracy within a simplified installation reduces OEM production time and cost
Frameless, compact design for reduced weight and design envelope. Large bore and low axial height for use in rotary actuators
Providing accurate and robust position measurement
Repeatable, accurate and high Resolution absolute position feedback

Mechanical Specifications

Specification	CORE-1-44	CORE-3-70
Stator OD	44 mm	70 mm
Rotor ID	10.4 mm	30.3 mm
Height	12.1 mm	13.4 mm
Rotor Mass	3 g	6.5 g
Stator Mass	12 g	22.5 g
Nominal Axial Gap	0.5 mm	1.1 mm
Axial Gap Tolerance	±0.2 mm	±0.35 mm
Radial Offset Tolerance	0.2 mm	0.25 mm
Material	PCB – FR4	PCB – FR4

General Specifications

Specification	CORE-1-44	CORE-3-70
Measurement	Absolute	Absolute
Max Resolution	17 bits	20 bits
Repeatability	±1 count	±1 count
Accuracy	±360 arcseconds	±125 arcseconds
Internal Position Update Period	<0.1 ms	<0.1 ms
Thermal Drift Coefficient	<1 ppm/K Full-Scale	<1 ppm/K Full-Scale
Max. Speed for Angle Measurement (0.1 millisecond update rate)	10,000 rpm	10,000 rpm
Max. Speed	10,000 rpm	10,000 rpm
Country of Manufacture	UK	UK

Electrical Specifications

Specification	Value
Communications	SSI, BiSS-C, Asynch serial, SPI
Data Outputs	RS422
Power Supply	4.5 – 5.5, 8–12 VDC
Current Consumption	< 100 mA (typically < 75 mA)
Interconnection	Molex 10-way connector

Environmental Specifications

Specification	Value
Vibration	20g for 10-2000Hz (IEC 60068-2-6 20g), DEF STAN 00-35 : Part 3 : Issue 4 Test M1 Vibration, A24 & A25 – Heavy Tracked Vehicles
EMC Radiation Susceptibility	(Installed) Complies with IEC 61000-6-2 – suitable for fitment in harsh EMC environments
EMC Radiated Emissions	(Installed) Complies with IEC 61000-6-4 – suitable for fitment adjacent to EMI sensitive devices
Operating Temp.	–20°C to +85°C
Storage Temp.	–55°C to +105°C (–60°C to +105°C for 24CT option)
IP Rating – Rotor & Stator	IP00
IP Rating – Connector	IP00
