Tip/Tilt Piezo Stages
Tip/tilt piezo stages provide ultra-precise angular positioning, enabling controlled rotation about two axes for beam steering, alignment, and stabilization tasks. Using piezoelectric actuation and flexure-based designs, these stages deliver smooth, backlash-free motion with nanoradian-level resolution and fast dynamic response. Unlike traditional linear stages, their unique architecture allows the platform to pivot about a central point, making them ideal for directing, stabilizing, or deflecting light sources in high-performance optical and photonic systems.
Tip/Tilt Piezo Stages
Tip/tilt piezo stages deliver ultra-precise angular positioning for beam steering, optical alignment, and dynamic stabilization in advanced photonics and imaging systems.
- Controlled pitch and roll motion about two orthogonal axes
- Piezoelectric actuation with flexure-guided, frictionless motion
- Backlash-free performance with nanoradian-level resolution
- High stiffness and exceptional repeatability for stable alignment
- Fast response and high bandwidth for real-time adjustment and correction
- Defined pivot point minimizes unwanted linear displacement
- Ideal for laser beam steering, adaptive optics, interferometry, and high-resolution imaging applications
Explore Our Tip/Tilt Piezo Stages
RXY3-276
A fast tip/tilt piezo stage designed for high-speed angular nanopositioning, offering up to 3 mrad of motion and optimized for precise beam steering with 1″ to 3″ mirrors.
Speak to an Engineer
Explore how Tip/Tilt Piezo Stages can streamline your workflows. Novanta has the right technology and Engineering team for your solution.
Explore Our Featured Applications
Tip/Tilt Piezo Solutions
Laboratory Automation
Lab automation uses advanced instrumentation and motion systems to streamline and standardize experimental workflows, improving accuracy, throughput, and repeatability in research and diagnostic environments.
Semiconductor
Semiconductor manufacturing relies on ultra-precise motion and automation systems to enable high-speed, nanoscale fabrication, inspection, and alignment of integrated circuits.
Features of Tip/Tilt Piezo Stages
Fast Tip-Tilt Motion
Mirror-Ready Platform
High-Speed Response
Low Noise Accuracy
