Everest Safe

Safety is not an accident.

Maximum Power Meets Advanced Safety

Everest Safe is our most powerful servo drive, engineered for the most demanding motion control applications. Built on the proven Everest platform, it now integrates Safety over EtherCAT (FSoE), ensuring compliance with the highest functional safety standards without compromising performance.

This combination of raw power and advanced safety makes Everest Safe the ideal choice for high-performance robotics, industrial automation, and any application where precision and protection are critical.

To product features

Embedded Safety

Everest came to the market as the slimmest, highest power-density servo drive. Today, Everest is not only that, but it now features the latest and most advanced safety certifications – more than 12 SIL3 PLe CAT3 certified safety functions. FSoE, STO, safe GPIOs and a plethora of functional certified safety functions (SS1, SS2, SP, SV, among others), without any sacrifice in performance.

To Safety Specifications

Overview & Features

Specifications

Documentation & Manuals

Overview

Features & Benefits

Advanced functional safety functions
Highest power density
45 A continuous / 60 A peak
Up to 100 kHZ PWM frequency
Up to 99% efficiency
Standby power consumption down to 1.7 W
EtherCAT embedded communications
FSoE (Functional Safety over EtherCAT) rated up to SIL-3 PLe

Read more specifications

Specification	Value
Part number	EVS-S-NET
Rated/Peak current	45 A (60 A peak)
Voltage	60 VDC
Size	37 x 28.5 x 17.14 mm
Efficiency	Up to 99%
Minimum Standby Power Consumption	1.7 W
Feedback sensors (motion control)	Supports Digital Halls, Quadrature Incremental encoder, Absolute BiSS-C encoder, SSI
Communications	FSoE (FailSafe over EtherCAT)
Safety Feedback Combinations	2x BiSS-C BP3; 1x BiSS-C BP3 + QEI; 1x BiSS-C BP3 + Halls; QEI + Halls
Safety	FSoE, STO, SS1-r, SS2-t, SS2-r, SOS, SLS, SSR, SLP, SLI, SDI, SV (SIL3 PLe CAT3)
